Processor

AMD Ryzen™ Z1 Extreme (8C / 16T, 3.3 / 5.1GHz, 8MB L2 / 16MB L3)

Graphics

Integrated AMD Radeon™ Graphics

Chipset

AMD SoC Platform

Memory

32GB Soldered LPDDR5X-7500

Memory Slots

Memory soldered to systemboard, no slots

Max Memory

32GB soldered memory, not upgradable

Storage

1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot

One M.2 2280 PCIe® 4.0 x4 slot

Max Storage Support

One drive, up to 1TB M.2 2242 SSD

Optical

None

Card Reader

microSD Card Reader

Audio Chip

High Definition (HD) Audio

Speakers

Stereo speakers, 2W x2

Microphone

2x, Array

Camera

None

Battery

55.5Wh

Power Adapter

65W USB-C® Slim (2-pin, Wall-mount)

Special Features

Legion Coldfront cooling system

Display

8" WUXGA (1920x1200) IPS 500nits Glossy / Anti-fingerprint, 100% sRGB, 48-120Hz VRR, Panda King Glass, Low Blue Light, Touch

Touchscreen

In-cell, 10-point Multi-touch

Screen-to-Body Ratio

83% AAR (active area ratio)

Pen

Pen Not Supported

Touchpad

Buttonless Mylar® surface touchpad (on the right controller), 10 x 10 mm (0.39 x 0.39 inches)

Controls

A B X Y buttons D-pad Touchpad Left & right Joysticks 4x function buttons Y1 & Y2 buttons LT & RT buttons LB & RB buttons LT & RT button range switch

Dimensions (WxDxH)

298.5 x 127.55 x 22.6-43.4 mm (11.75 x 5.02 x 0.89-1.71 inches)

Weight

Around 740 g (1.63 lbs)

Case Color

Nebula Nocturne

Case Material

PC-ABS + 15% Talc

Surface Treatment

Painting + Laser Special Texture

Others

• Power button
• Volume keys

Operating System

SteamOS

Bundled Software

None

WLAN + Bluetooth

AMD Wi-Fi® 6E RZ616, 802.11ax 2x2 + BT5.3

WWAN

WWAN Not Supported

Ethernet

No Onboard Ethernet

Standard Ports

• 2x USB-C® (USB4® 40Gbps), with USB PD 65-100W and DisplayPort™ 1.4
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Card reader

Docking

Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion Go S 8APU1

Security Chip

Firmware TPM 2.0 Enabled

Fingerprint Reader

No Fingerprint Reader

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

1Y Accidental Damage Protection One Add On

Bundled Accessories

None

Green Certifications

• ErP Lot 6/26
• RoHS compliant

Other Certifications

TÜV Rheinland® Low Blue Light (Hardware Solution)
